Home > Electrical & Electronics > Variable-Frequency Drive > 36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor

36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor

36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor photo-1
36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor photo-2
36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor photo-3
36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor photo-4
36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated Products NEMA23 Motor photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
2008
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor

Product Description



Feature:
- The DM556 is a versatility fully digital stepper drive based on a DSP with advanced control algorithm. The DM556 is the next generation of digital stepper motor controls. It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability. Motor self-test and parameter auto-setup technology offers optimum responses with different motors and easy-to-use. The driven motors can run with much smaller noise, lower heating, smoother movement than most of the drives in the markets. Its unique features make the DM556 an ideal solution for applications that require low-speed smoothness.

- Compared to the DM432, broader input voltage and output current ranges make the DM556 able to drive much more motors than the DM432. What’s more, owing to its higher performance DSP, driven motors can achieve much higher speed (above 3000RPM) than that of the DM432, offering servo-like performances.

Features:
- Heatsink integrated and connectors included
- Input: 20 to 50 VDC; Output: 0.5 and 5.6A
- Utility software for tuning drive parameters from a desktop computer
- Super low noise; super low motor heating; extra smooth at low speed
- Anti-Resonance, provides optimum torque and nulls mid-range instability
- Motor self-test and parameter auto-setup technology, offers optimum responses with different motors
- Multi-stepping allows a low resolution step input to produce a higher microstep output for smooth system performance
- Microstep resolutions programmable, from full-step to 102,400 steps/rev
- Output current programmable, any value between 0.5A and 5.6A
- Pulse input frequency up to 200 KHz
- TTL compatible and optically isolated input
- Automatic idle-current reduction
- Suitable for 2-phase and 4-phase motors
- Support PULSE/DIRECTION and CW/CCW modes
- Over-voltage, over-current, phase-error protections
- Dimensions: 4.65 X 2.97 X 1.34 inches; 9.9 oz
- CE certified

36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor36-60 VDC 2.1A to 5.6A Leadshine DM556 2-phase Digital Stepper Drive for Associated products NEMA23 motor
